XL Extendable Trailers

by Western Truck and Trailers

Over-length loads have finally met their match. XL Specialized trailer's extendable product line has every configuration you need to get the job done. XL has the patented XL Extend Attract System which is designed with the operator in mind. This system allows for extending and retracting the trailer without having to hook and unhook air, electrical, and hydraulic lines. XL's extendable product lines are available in several design options for deck length, width, and height. There are also many different neck styles available so you can customize your trailer to your needs.

Features

Proven Extendable Innovation

Operate the deck extension and retraction effortlessly—no need to disconnect air or electrical lines.
Enjoy seamless movement with four 6-inch rollers that can be easily lubricated.
Benefit from a robust one-piece track design that enhances overall stability.
Choose from a range of deck heights designed to meet your specific needs.

Versatile Hauling

A 28'7" deck that expands to 49'11", perfect for transporting long cargo.
Easily extend for lengthy loads and retract when extra space isn't needed.
The gooseneck design offers seven distinct ride height options.
Includes fourteen ½-inch chain drops on each side.
Features eight bent D-rings per side.
Comes with removable swing-out outrigger brackets spaced at 24-inch intervals.

Enhanced Stability and Efficient Weight Distribution for Safe Hauling

Durable one-piece structure made from 100k flange and 80k web
Apitong decking is standard for a rugged deck and added peace of mind

Featured Models

80 HDEM

80,000 lbs closed Overall Capacity

80,000 lbs in 16' closed Concentrated Capacity

XL’s mini-deck extendable offers the best of both worlds with a low deck height and extra-long load capability
Features a 14-inch loaded deck height with 4 inches of ground clearance
Main deck extends to 49′ 8″ when fully opened
Extension stops every two feet for versatile length adjustments

Get a quote

80 HDE

80,000 lbs closed Overall Capacity

80,000 lbs in 16' closed Concentrated Capacity

Main deck can range from 28 feet, 7 inches long to 49 feet, 11 inches long
9-foot long rear bridge
Enjoy XL’s easy to use extend-a-trac system which does not require hooking and unhooking lines
This 2-axle trailer can accommodate a 36-inch flip neck

Get a quote

90 HDE

90,000 lbs Overall Capacity

90,000 lbs in 10' Concentrated Capacity

Main deck can range from 28 feet, 7 inches long to 49 feet, 11 inches long
9-foot long rear bridge
Enjoy XL’s easy to use extend-a-trac system which does not require hooking and unhooking lines
This 2-axle trailer can accomodate a 36-inch flip neck
