Felling FT-70-2 OTR-L Flatbed Trailer

Felling FT-70-2 OTR-L Semi-Commercial

The Felling FT-70-2 OTR-L is a high-capacity semi-commercial trailer designed for heavy-duty transport. With its durable construction, advanced suspension system, and efficient load distribution, it ensures top-tier performance for industrial and commercial applications.

General Specifications

• Overall Length: 48'
• Approximate Weight: 12,500 lbs
• Load Capacity: 70,000 lbs Distributed, 45,000 lbs in 10', 41,500 lbs in 4'
• Upper Deck: 90 Degree Neck
• Deck Length: 38'
• Frame Type: Pierced 4" (80K) JR I-Beam Crossmembers, 12" On Center
• Frame Type: Wheel Boxes
• Deck Type: 1 1/8" Apitong Wood
• Approximate Deck Height: 59" Upper Deck, 35" Main Deck (Loaded)
• Width: 102" OD

Load Securing Features

• Tie Downs: Rub Rail & Stake Pockets with Double Pipe Spools

Axles & Suspension

• Axles: 25K Oil Bath
• Suspension: 10' 1" Spread, Ridewell 260 Air Ride with Dump Valve

Brakes & Safety

• Brakes: Air, ABS 2S/1M, Meritor WABCO (Parking Brakes on All Axles)

Wheels & Tires

• Tires & Wheels: 235/75R 17.5 J, 8 Bolt [17.5 x 6.75] Hub Pilot

Hitch & Jack

• Hitch Type: Semi King Pin(s) with 18" Setback, 48" Height
• Jack: 200,000# Twin 2 Speed, Holland Mark V (62,500 lb Lift Capacity)

Electrical & Lighting

• Plug: 7 Pole Semi Socket
• Lights: LED Lights (Peterson), (3) Lights per Side Deck, (3) per Side Tailboard, Sealed Wiring Harness (Sealco)

Additional Features

• Trailer Color: Felling Black
• Stripe Color: White
• Standard: Ready for a 60" Chain Box on Both Sides, Located Behind Dollies
• Standard: Document Holder
• GVWR: 82,500 lbs

Why Choose Felling FT-70-2 OTR-L?

With its robust build, advanced safety features, and high load capacity, the Felling FT-70-2 OTR-L is an ideal solution for heavy-duty hauling, ensuring efficiency, durability, and long-term reliability.
