SAW T603 30-TON TILT DECK
DIMENSIONS:
- 36' OVERALL LENGTH
- 5' TONGUE
- 5' STATIONARY DECK
- 26' TILT DECK
- 36 ½" DECK HEIGHT
- 102" WIDE
DECKING:
- (6) D-RINGS PER SIDE
- WOOD DECKING
- STEEL FENDER WHEEL WELLS
- MECHANICAL CAM-OVER DECK LOCKING SYSTEM
TIRES & WHEELS:
- (12) 215/75R17.5 RADIAL TIRES
- 8-HOLE STEEL DISC WHEELS
FRAME:
- FORMED NOSEPIECE WITH ADJUSTABLE PINTLE EYE LOAD HEIGHTS FROM 17" TO 36" IN 2" INCREMENTS
- BLOCK TRAY
- 2-SPEED JACKLEG
- SAFETY CHAINS
- HEAVY DUTY 16" MAIN FRAME W/ FRAME REINFORCEMENTS AT TRANSITIONS
- BOXED REINFORCEMENT AT 10" REAR FRAME TRANSITION
AXLES & SUSPENSION:
- (3) 20,000 LBS AXLES
- 49" AXLE SPACING
- HUTCH 9700 SPRING SUSPENSION
- ABS (4S/1M)
ELECTRICAL, PAINT & SAFETY:
- FOLD UP REAR LIGHT BAR
- LED LIGHTS
- WIRE IN LOOM
- LICENSE PLATE HOLDER
- SANDBLASTED, PRIMED & PAINTED WITH POLYURETHANE PAINT
- CONSPICUITY TAPE
