SmithCo 10-axle train (4-2) Side Dump Trailer

SMITHCO 10-Axle Train – 4-Axle Lead, 2-Axle Pup

The SMITHCO 10-Axle Train is an advanced side dump trailer system built for high-capacity hauling with durability and efficiency in mind.

General Specifications

• 4-Axle Lead: 46’ Overall Length
• 2-Axle Pup: 34’ Overall Length
• Overall Train Length: 81’
• Overall Width: 102”
• Capacity: 35.4 cubic yards (Level Full), 47.7 cubic yards (Heaped)

Frame & Tub Construction

• Material: AR400 Steel Construction
• Frame: High-Tensile, Tapered
• Tub Style: Rounded for Reduced Material Sticking
• Side Construction: Solid Steel
• Center Stabilizer: Low-Slung
• Drainage: Water-Tight Tub with Drain Plugs
• Valve System: Trailer-Mounted Electric-Over Hydraulic with Power Beyond
• Landing Legs: 2-Speed (Lead)
• Fenders: Front & Rear

Undercarriage

• Suspension: Air Ride (All Axles)
• Lift Axle: 1st Axle Air Lift (Lead)
• Steerable Axle: 4th Axle Steerable Air Lift (Lead)
• Lead Tires: (6) 385/65R22.5 Super Single Radial Tires
• Pup Tires: (2) 11R22.5 Radial, (4) 385/65R22.5 Radial
• Suspension Stabilization: Immediate Response Valve
• Axle Track (Lead): 77 1/2” Wide
• Axle Capacity (Lead): (3) Axles Rated at 25,000 lbs
• Axle Track (Pup): 83 1/2” Wide
• Axle Capacity (Pup): (2) Axles Rated at 18,740 lbs
• Wheels: Hub-Piloted Aluminum (All)
• Hubs: Outboard Hubs, Cast Drums, Oil Bath

Braking & Safety

• ABS (Lead): 2S1M Anti-Lock Braking System
• ABS (Pup): Anti-Skid Brake Sensor on 1st Axle

Additional Features

• Push Block: Bolt-On
• Lighting: LED Lights with Theft-Proof Bezels
• Tarp System: Electric
• Towing Package: Complete with Hydraulics

Why Choose the SMITHCO 10-Axle Train?

The SMITHCO 10-Axle Train delivers maximum hauling capacity with precision-engineered stability, advanced hydraulics, and high-strength materials to ensure efficiency and durability.
